Power: 22-26 VAC/DC
Sensing Tech: PIR+HFD
Output: Form C dry contact
Setting: Manual
Mount: Wall, ceiling, or corner
Connection: Lead wire
Coverage: Fixed
Compliance: FCC, CA24
- ECG for 0-10V Continuous Dimming Control
- Ambient light levels selectable to inhibit relay
- HFD sensitivity adjustable for optimum range
- 22-26 VAC/DC low voltage power operation
- NC-COM-NO form C dry contact relay output
- Multi‑directional mounting bracket included
- Selectable ON-delay to filter walk-by traffics
- 3 LED's indicate occupancy sensing activities
- SmartDelay enables smart delay time setting
- Walk-through mode available for more saving
- Audible Delay-End Warning enabled/disabled
- Manual override control signal input available
- 5-minute TEST mode with shortest OFF-delay
- Available for wall/corner/ceiling mount
- Pigtail wires for easy connection
