IR-TEC International Ltd.

PBD-720W
Push-Button Dimmer Switch

The PBD-720W is a single pole, low voltage push‑button dimmer switch designed to fit into a standard NEMA wall box. This sleek, low profile switch provides a momentary contact signal for IR‑TEC power pack to manually control the connected lighting, together with an adjustable 0‑10V output to dim the light as desired through intuitive button operation.

Pluggable type terminal block makes low voltage wiring connection quick and easy. A screwless snap‑on Decora wall plate is supplied to create a modern, high‑end appearance for all spaces.

Features
Downloads

Power: 12-24 VDC
Pole: 1-pole
Setting: None
Mount: NEMA
Connection: Plug
Control signal: Momentary contacts and 0-10V
Compliance: uL, CA24

Low profile, optimal décor aesthetics
0‑10V output for manual dimming
Momentary contact signal control
Screwless wall plate offers high end appearance
Install friendly pluggable terminal

Product Information

PBD-720 Datasheet
PBD-720 Installation Instruction

Design tools

CAD Symbols

Features

Power: 12-24 VDC
Pole: 1-pole
Setting: None
Mount: NEMA
Connection: Plug
Control signal: Momentary contacts and 0-10V
Compliance: uL, CA24

Low profile, optimal décor aesthetics
0‑10V output for manual dimming
Momentary contact signal control
Screwless wall plate offers high end appearance
Install friendly pluggable terminal
